Product Summary

The SN74LS138NSR is a 3-line to 8-line decoder/demultiplexer. It is designed to be used in high-performance memory decoding or data-routing applications requiring very short propagation delay times. In high-performance memory systems, the SN74LS138NSR can be used to minimize the effects of system decoding. The device is characterized for operation over the full military temperature range of 0℃ to 70℃.

Parametrics

SN74LS138NSR absolute maxing ratings: (1)Supply voltage VCC: 7V; (2)Input voltage: 7V; (3)Operating free-air temperature range: 0℃ to 70℃; (4)Storage temperature range: -65℃ to 150℃.

Features

SN74LS138NSR features: (1)designed specifically for high-speed:memory decoders, data transmission systems; (2)3 enable inputs to simplify cascading and/or data reception; (3)schottky-clamped for high performance.

Diagrams

SN74LS138NSR circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74LS138NSR
SN74LS138NSR
Texas Instruments
Encoders, Decoders, Multiplexers & Demultiplexers 3-line to 8-line Decoder/Demltplxr
Data Sheet
0-1: $0.45
1-25: $0.41
25-100: $0.35
100-250: $0.31
SN74LS138NSRE4
SN74LS138NSRE4
Texas Instruments
Encoders, Decoders, Multiplexers & Demultiplexers 3-line to 8-line Decoder/Demltplxr
Data Sheet
0-1: $0.45
1-25: $0.37
25-100: $0.32
100-250: $0.28
SN74LS138NSRG4
SN74LS138NSRG4
Texas Instruments
Encoders, Decoders, Multiplexers & Demultiplexers 3Ln to 8Ln Decodr Demultiplexer
Data Sheet
0-1: $0.45
1-25: $0.37
25-100: $0.32
100-250: $0.28
