KTC3875S-GR-RTK/P

SOT-23, Excellent hFE Linearity, 150 mA, semiconductor, VCEO 50 V, Low Noise NF 1dB, High hFE

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.02~0.02 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.02~0.02

PartNumber:: KTC3875S-GR-RTK/P

Brand:: KEC(Korea Electronics) - KEC | Pack: SOT | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. sales's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-08

From Other Seller

Part Number:KTC3875S-GR-RTK/P
US $0.02 - 0.02
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The KTC3875S-GR-RTK/P is a semiconductor. The KTC3875S-GR-RTK/P has general purpose application and switching application.

Parametrics

KTC3875S-GR-RTK/P maximum rating: (1)Collector-Base Voltage VCBO: 60 V; (2)Collector-Emitter Voltage VCEO: 50 V; (3)Emitter-Base Voltage VEBO: 5 V; (4)Collector Current IC: 150 mA; (5)Base Current IB: 30 mA; (6)Collector Power Dissipation PC: 150 mW; (7)Junction Temperature Tj: 150℃; (8)Storage Temperature Range Tstg: -55 to 150℃.

Features

KTC3875S-GR-RTK/P features: (1)Excellent hFE Linearity: hFE(0.1mA)/hFE(2mA)=0.95(Typ.); (2)High hFE: hFE=70 to 700; (3)Low Noise: NF=1dB(Typ.), 10dB(Max.); (4)Complementary to KTA1504S.
