Product Summary

The HCPL-0630-500E is the optically coupled line receiver that combines a GaAsP light emitting diode, an input current regulator and an integrated high gain photo detector. The input regulator serves as a line termination for line receiver applications. HCPL-0630-500E clamps the line voltage and regulates the LED current so line reflections do not interfere with circuit performance. The regulator allows a typical LED current of 8.5 mA before it starts to shunt excess current.

Parametrics

HCPL-0630-500E absolute maximum ratings: (1)Storage Temperature: -55 to 125 ℃; (2)Operating Temperature: -40 to 85 ℃; (3)Forward Input Current: 60 mA; (4)Reverse Input Current: 60 mA; (5)Input Current, Pin 4: -10 to 10 mA; (6)Supply Voltage (1 Minute Maximum): 7 V; (7)Enable Input Voltage (Not to Exceed VCC by more than 500 mV): VCC + 0.5 V; (8)Output Collector Current: 50 mA; (9)Output Collector Voltage (Selection for Higher Output Voltages up to 20 V is Available.): 7 V; (10)Output Collector Power Dissipation: 40mW.

Features

HCPL-0630-500E features: (1)1000 V/μs Minimum Common Mode Rejection (CMR) at VCM = 50 V for HCPL-2602 and 3.5 kV/μs Minimum CMR at VCM = 300 V for HCPL-2612; (2)Line Termination Included No Extra Circuitry Required; (3)Accepts a Broad Range of Drive Conditions; (4)LED Protection Minimizes LED Efficiency Degradation; (5)High Speed: 10 MBd (Limited by Transmission Line in Many Applications); (6)Guaranteed AC and DC Performance over Temperature: 0 to 70℃; (7)Safety Approval UL Recognized-2500 V rms for 1 Minute CSA Approved; (8)MIL-STD-1772 Version Available (HCPL-1930/1).

Diagrams

HCPL-0630-500E functional diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
HCPL-0630-500E
HCPL-0630-500E

Avago Technologies

High Speed Optocouplers 10MBd 2Ch 5mA

Data Sheet

0-1: $3.04
1-25: $2.48
25-100: $2.21
100-250: $1.99
