Product Summary

The PI3USB10MZKEX is a single differential channel 2:1 multiplexer/demultiplexer USB 2.0 Switch. Industry leading advantages include a propagation delay of less than 250ps, resulting from its low channel resistance and I/O capacitance. The PI3USB10MZKEX multiplexes differential outputs from a USB Host device to one of two corresponding outputs. The switch is bidirectional and offers little or no attenuation of the high-speed signals at the outputs. PI3USB10MZKEX is designed for low bit-to-bit skew, high channel-to-channel noise isolation and is compatible with various standards, such as High Speed USB 2.0 (480 Mb/s).

Parametrics

PI3USB10MZKEX absolute maximum ratings: (1)Storage Temperature: –65℃ to +150℃; (2)Supply Voltage to Ground Potential: –0.5V to +4.0V; (3)DC Input Voltage: –0.5V to +5.5V; (4)DC Output Current: 120mA; (5)Power Dissipation: 0.5W.

Features

PI3USB10MZKEX features: (1)USB 2.0 compliant; (2)RON is 4Ω typical; (3)Low bit-to-bit skew; (4)Low Crosstalk: -31dB @ 250MHz; (5)Near-Zero propagation delay: 250ps; (6)Switching speed: 9ns; (7)Channel On Capacitance: 6pF (typical); (8)VCC Operating Range: 2.7V to 4.2V ± 10%; (9)ESD>2000V, Human Body Model; (10)>700 MHz bandwidth (or data frequency).

Diagrams

PI3USB10MZKEX Block Diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PI3USB10MZKEX
PI3USB10MZKEX
Pericom
Multiplexer Switch ICs Dual SPDT Mux 3.3V
Data Sheet
0-17500: $0.33
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PI3USB102ZLEX
PI3USB102ZLEX
Pericom
Power Switch ICs - USB 2.1 USB High speed singal SWT
Data Sheet
0-3500: $0.46
3500-7000: $0.43
7000-10500: $0.39
PI3USB102ZMEX
PI3USB102ZMEX
Pericom
Power Switch ICs - USB Dual SPDT for USBHSapplication
Data Sheet
0-3000: $0.39
3000-39000: $0.39
PI3USB10LP-AZLEX
PI3USB10LP-AZLEX
Pericom
Power Switch ICs - USB Dual SPDT for USB 2.0 HS
Data Sheet
0-3500: $0.46
3500-7000: $0.43
7000-10500: $0.39
PI3USB10LP-AZMEX
PI3USB10LP-AZMEX
Pericom
Power Switch ICs - USB Dual SPDT Mux 3.3V
Data Sheet
0-3000: $0.43
3000-6000: $0.41
6000-12000: $0.40
PI3USB10MZKEX
PI3USB10MZKEX
Pericom
Multiplexer Switch ICs Dual SPDT Mux 3.3V
Data Sheet
0-17500: $0.33
PI3USB10ZEEX
PI3USB10ZEEX
Pericom
Multiplexer Switch ICs USB 2.0 Switch Mux/Demux 3.3V
Data Sheet
0-1: $1.01
1-25: $0.92
25-50: $0.83
50-100: $0.73
