Product Summary

The BC847S E6327 is a NPN general-purpose transistor.

Parametrics

BC847S E6327 absolute maximum ratings: (1)Collector-emitter voltage VCEO: 45 V; (2)Collector-base voltage VCBO: 50V; (3)Collector-emitter voltage VCES: 50V; (4)Emitter-base voltage VEBO: 6V; (5)DC collector current IC: 100 mA; (6)Peak collector current ICM: 200mA; (7)Total power dissipation, TS = 115 ℃ Ptot: 250 mW; (8)Junction temperature Tj: 150 ℃; (9)Storage temperature Tstg: -65 to 150℃.

Features

BC847S E6327 features: (1)For AF input stages and driver applications; (2)High current gain; (3)Low collector-emitter saturation voltage; (4)Two ( galvanic) internal isolated Transistors with good matching in one package.

Diagrams

BC847S E6327 diagram
