Product Summary
The MACH210AQ-12JC is a High-Density EE CMOS Programmable Logic. It has approximately six times the logic macrocell capability of the popular PAL22V10 without loss of speed. The MACH210AQ-12JC consists of four PAL blocks interconnected by a programmable switch matrix. The MACH210AQ-12JC output macrocell provides registered, latched, or combinatorial outputs with programmable polarity. If a registered configuration is chosen, the register can be configured as D-type or T-type to help reduce the number of product terms.
Parametrics
MACH210AQ-12JC absolute maximum ratings: (1)Storage Temperature:–65℃ to +150℃; (2)Ambient Temperature with Power Applied:–55℃ to +125℃; (3)Supply Voltage with Respect to Ground:–0.5 V to +7.0 V; (4)DC Input Voltage:–0.5 V to VCC + 0.5 V; (5)DC Output or I/O Pin Voltage:–0.5 V to VCC + 0.5 V; (6)Static Discharge Voltage:2001 V; (7)Latchup Current (TA = 0℃ to +70℃):200 mA.
Features
MACH210AQ-12JC features: (1)44 Pins; (2)64 Macrocells; (3)7.5 ns tPD Commercial, 12 ns tPD Industrial; (4)133 MHz fCNT; (5)38 Inputs; 210A Inputs have built-in pull-up resistors; (6)Peripheral Component Interconnect (PCI) compliant; (7)32 Outputs; (8)64 Flip-flops; 2 clock choices; (9)4 “PAL22V16” blocks with buried macrocells; (10)Pin-compatible with MACH110, MACH111, MACH211, and MACH215.
Diagrams
 |
