IS42S16800A-7TL

TSOP54, 16Meg x 8, 8Meg x16, 4Meg x 32, 128-Mbit, synchronous DRAM, –0.5 to +4.6 V, 1 W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.85~1.90 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.85~1.90

PartNumber:: IS42S16800A-7TL

Brand:: Integrated Circuit Solution Inc - ISSI | Pack: TSOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. sales's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-01

From Other Seller

Part Number:IS42S16800A-7TL
US $1.85 - 1.90
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IS42S16800A-7TL is the 16Meg x 8, 8Meg x16, 4Meg x 32 128-Mbit synchronous DRAM which achieves high-speed data transfer using pipeline architecture. The IS42S16800A-7TL 128Mb SDRAM includes an AUTO REFRESH MODE, and a power-saving, power-down mode. All signals are registered on the positive edge of the clock signal, CLK. All inputs and outputs are LVTTL compatible. Programmable READ or WRITE burst lengths consist of 1, 2, 4 and 8 locations or full page, with a burst terminate option.

Parametrics

IS42S16800A-7TL absolute maximum ratings: (1)Maximum Supply Voltage: –0.5 to +4.6 V; (2)Maximum Supply Voltage for Output Buffer: 0.5 to +4.6 V; (3)Input Voltage: –0.5 to +4.6 V; (4)Output Voltage: –0.5 to +4.6 V; (5)Allowable Power Dissipation: 1 W; (6)Output Shorted Current: 50 mA; (7)Operating Temperature: 0 to +70 ℃, –40 to +85℃; (8)Storage Temperature: –55 to +125 ℃.

Features

IS42S16800A-7TL features: (1)Clock frequency: 166,143,100 MHz; (2)Fully synchronous; all signals referenced to a positive clock edge; (3)Internal bank for hiding row access/precharge; (4)Power supply: VDD=3.3V, VDDQ=3.3V; (5)LVTTL interface; (6)Programmable burst length (1, 2, 4, 8, full page); (7)Programmable burst sequence: Sequential/Interleave; (8)Auto Refresh (CBR); (9)Self Refresh with programmable refresh periods; (10)4096 refresh cycles every 64 ms; (11)Random column address every clock cycle; (12)Burst read/write and burst read/single write operations capability; (13)Burst termination by burst stop and precharge command; (14)Industrial Temperature Availability; (15)Lead-free Availability.
