Product Summary
CAP ALUM 47UF 6.3V 20% SMD; Tape & Reel (TR)
Features
General Purpose;Surface Mount;Radial, Can - SMD;
Diagrams
| Datasheets |
AFK Series |
|---|---|
| Product Photos |
AFK Series |
| Catalog Drawings |
AFK Series Bottom_B AFK Series_B |
| Standard Package | 2,000 |
| Category | Capacitors |
| Family | Aluminum Capacitors |
| Series | AFK |
| Capacitance | 47μF |
| Voltage Rating | 6.3V |
| Tolerance | ±20% |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Features | General Purpose |
| Ripple Current | 90mA |
| ESR (Equivalent Series Resistance) | 1.35 Ohm |
| Impedance | 1.35 Ohm |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.157" Dia (4.00mm) |
| Height - Seated (Max) | 0.228" (5.80mm) |
| Lead Spacing | - |
| Surface Mount Land Size | 0.169" L x 0.217" W (4.30mm x 5.50mm) |
| Packaging | Tape & Reel (TR) |
| Dynamic Catalog | AFK Series |
| Other Names |
338-2196-2 AFK476M06B12T-F-ND |
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AFK476M06B12T-F |
Cornell Dubilier |
Aluminum Electrolytic Capacitors - SMD 6.3V 47uF 4x5.8 |
